L5B03

Add to Inquiry Open Inquiry

Rated Impedance: 1666.6Ω(6W),3333.3Ω(3W),6666.6Ω(1.5W)
Rated Power: 6 W
Max. Power: 9 W
Sensitivity: 86 dB ± 3dB , 1W/1M
Frequency Range: 50 Hz ~ 17 KHz  -10dB / ±20% Hz
Whistling: 50  Volts   at  6 W Tap
Termination: Screw Terminal
Power Taps: 6-3-1.5W
Baffle: eel, RAL 9010
Mesh Grille: Steel, RAL 9010
Dimension: 172Фx 25 D mm
AC Input Voltage: 100V~240V
Typical view angle @ 1/2θ: 120°
Typical-light-flux-output@1A: 130 lm
Typical optical efficiency: 40 lm / W
Forward Voltage: 3.3V
Forward Current: 1008mA
Thermal @600min (T Ambient=25°C): < 50℃
Life Span: 30000 hrs
